一种盘式磁滞张力器控制器设计

打开文本图片集

中图分类号：TS103.7 文献标志码：B 文章编号：1671-5276（2025）06-0050-06

Abstract：Thispaperdesignsacontrollerforadischysteresis tensioner，whichincludes three modulesliketensioncontrolar breakage detectionandmaincontrol.ThetensioncontrolbasedonthePWMcontrol BOOSTcircuitcontrols thetensionerto output diffrenttensions，yarnbreakage detectionusesaphotoelectrictubetodetect diferent voltagesignalsduring yarnring， and maincontrold moduleutilizessinglechip microcomputer tooutputPWM waveswithdiferentdutycyclescontroling the tension，receivingandprocessng yarnrunningsignal.ThetestwasconductedtocalibratethePWMdutycycleandtensionof the tensioncontrol module，andtheinfluenceofyarsof diferent materialsonthetensionwasexplored.Andtheyarn breakage detectionvoltagesignal wasdetectedverifying thefeasibilityofyarnbreakagedetection.Thetestresultsshowthatthecontroller designing meets the working requirements of the tensioner.

Keywords：textilemachinery；yarn tensioner；BOOST circuit；single chip microcomputer；yarnbreak detection；PWM

0 引言

在现代纺织品织造工艺中整经阶段尤为重要，它要求每一根纱线的张力恒定一致，否则容易引起纱线断头或者粗纱冒纱等现象[1-2]。（剩余6433字）
