重载刮板机伺服驱动液压缸负载口独立调平控制方法

打开文本图片集

Abstract：The servo drive systemof heavy-dutyscraper faces challengesoflowdamping ratio and closed-loop stifess whentheload changes，and these characteristics willfluctuate with the displacementoftheload center of gravity and the tiltangleof the platform.Loadportindependentlevelingcontroltechnologyisadoptedtoaccuratelycontroltheoil source pressure and hydraulic pump output flow rate in real time，so as to adapt to the complex load conditions during the operation of heavy一duty scraper machines.A mathematical model is constructed to simulate the operating state and determine the criticalsuctionconditions，and anoil source pressure controlerand an adaptive flow controler based on an extended state observed are designed.The experimental results show that the heavy一dutyscraper machineexhibits good control performance and stabilityunder various loads and controlconditionsbyadopting the technolog.Especiallduring thecontrol process，thedisplacementof theproportionalvalveissignificantlyreduced，indicating thatthismethodnot only achieves precise control but also effectively reduces the energy consumption and wearof the hydraulic system.

Keywords：heavy-duty scraper；hydrauliccylinder load port；independent leveling control；state observer；oil source pressure；output flow

0 引言

重载刮板机在运行过程中，由于负载的变化和物料分布的不均匀，往往会导致刮板机各部位受力不均[1-2]，进而产生振动和倾斜。（剩余6253字）
