交流电传动重型轨道车转向架构架强度分析与研究

打开文本图片集

摘 要：为研究交流电传动重型轨道车转向架构架强度，利用有限元方法，针对电传动重型轨道车的转向架运用工况，对构架进行强度分析，并根据计算结果优化上盖板结构，再次进行静强度及模态分析。结果表明：其满足相关标准及应用需求。

关键词：轨道车辆；转向架构架；强度分析；疲劳分析；模态分析

中图分类号：U260.331  文献标志码：B  文章编号：1671-5276（2025）01-0104-05

Strength Analysis and Reserch on Bogie Frame of AC Transmission Heavy Rail Car

Abstract：To study the strength of the bogie frame of AC transmission heavy rail car， finite element method was applied to analyze the strength of the frame under the operating conditions of the bogie of the electric drive heavy rail motor car. The upper cover plate structure was optimized based on the calculation results， and static strength and modal analysis was performed again. The results showed that the relevant standards and application requirements were met.

Keywords：rail car; bogie frame; strength analysis; fatigue analysis; modal analysis

0 引言

近年来随着国家对铁路等基础建设的投资力度不断加大，我国铁路不断建设和开通运营，铁路工务系统在对铁路维护配套设备的需求量增加的同时对其也提出了更高的要求［1］。（剩余2896字）
