高速磁浮列车抗侧滚扭杆装置研制

打开文本图片集

关键词：高速磁浮列车；抗侧滚；扭杆装置；悬浮架；研制；试验验证中图分类号： U292.91+7 文献标志码：B doi：10.20213/j. cnki. tdcl.2025.01.010

Abstract：In order to improve the anti-rollperformance of high-speed maglev trains and restrict the rolling motion of the carbody，a new anti-rollbar suitable for the suspension system of high-speed maglev trains was developedaccording to the design requirements of high-speed maglev trains.This paper presents in detail its design scheme，mechanical performance analysis and related test verification.The strength and fatigue life of the whole anti-roll barunder fatigue loadare checked by finite element analysis，and on this basis，the performance of fatigue is analyzed by Fe-Safe software，and the analysis results meet the requirements of fatigue design；At the same time，the anti-roll bar is subjected to system stiffess test，elastic test，fatigue test，and stiffness and fatigue test of bar connecting rod joint. Simulation analysis and test results show that the strength，stifnessand manufacturing processof teanti-rollbarfullymeettheapplicationrequirementsof the highspeed maglev train，and provide strong support for the safety，stability and comfort of the train operation.

Key words： high-speed maglev train; anti-roll; torsion bar; suspension system; development; test

目前国内外大部分高速客车和城轨车辆转向架均采用了抗侧滚扭杆装置，以有效抑制车辆的侧滚角，降低车辆的柔度系数[1]。（剩余6796字）
