基于AutoCAD二次开发的某物流园区换热站智能电缆绘图系统研发

打开文本图片集

中图分类号：F253.90 文献标志码：A DOI： 10.13714/j.cnki.1002-3100.2025.15.012

Abstract：Withthecontinuousdevelopmentofintellgentconstructioninlogisticsparks，thedesignofcableconetiondiagams forheatingelectromechanicalequipmentinsuchparksfaceschallngessuchashighcomplexity，lowtolefciencyandhigh colaborationcosts，eadingtoprolongeddesigntimes.Toaddresstheseissues，thisstudyproposesanintellgentcableoection diagramgenerationsystemthatintegratesparametricdesignwitharuleengine.Byleveraging VB6.Oprogrammingforsecondary developmentofAutoCADthesystemrealizesthreecorefunctions：Intellgentparsingofequipmentcodes，dynamiclayoutplan ning，andautomaticcableparameter matching.Verfiedthroughaheating electromechanicalequipmentprojectataheatexchange stationinalogisticspark，thesystemreducedthetimerequiredtogenerateasingledrawingfrom5hoursto15minutes.Under theconditionofcorrctinputparameters，theerrorrateindrawingproductiondecreasedfrom8.7%toO，signfcantlyimproving the efficiency and quality of intelligent construction design in logistics parks.

Keywords：intellgentconstruction;logisticsyardheatingelectromechanicalequipment;AutoCAD;VB6.0;intellgentcablecon nection diagram generation system

1绪论

1.1行业现状与创新价值

随着智能建造技术的快速发展，AutoCAD VB6.0 因其低代码特性与 AutoCAD 原生的优势，在机电工程领域得到了广泛应用。（剩余5314字）
