变容热处理炉温度调节系统的设计与应用效果分析

打开文本图片集

Design and Application Effect Analysis of Temperature Regulation SystemforVariable-volumeHeatTreatmentFurnace

Xia Jizhen

(Henan Tianli Thermal Equipment Co.,Ltd.,Xinxiang,Henan 453200)

Abstract:This paperaddresss theisuesoflarge temperaturefluctuations,highenergyconsumption,andlowinteligence intraditional heattreatmentfurnacesbydesigningatemperatureregulationsystemforavariable-volumeheattreatment furnace.Through anL-typetransmission mechanism,thefurnacevolume is switched between 25mand16m.Combined with 22- zoneindependent temperature control,fuzzy PIDalgorithm,anda "variable-frequency airadjustment + electric butterfly valve" cooling technology,the furnace temperature uniformityisimproved to )±3.5C ,the cooling rate control accuracy reaches ±5C/h ,the unit energy consumption is reduced by 18.7% ,and nitrogen oxide emissions are decreased by 80% .Industrial applications show that thequalified rate of workpiece heat treatment increases from 82% to97 % ,and the production cycle is shortened by 33% . The study indicates that future improvements can be made through machine learning,5Gcommunication,andwasteheatenergystorage technologiestofurtherenhancesystemadaptabilityandintelligence, providing a technical paradigm for the green transformation of the manufacturing industry.

Key words:variable-volume heat treatment furnace;temperature regulation system;fuzzy PID control; energy consumption optimization; green manufacturing

1研究背景

1.1热处理技术在制造业中的战略地位热处理作为装备制造业的核心基础工艺，直接决定了金属材料的性能、寿命与可靠性，是提升机械产品竞争力的关键环节。（剩余11215字）
