前镜参考型非定域干涉测角系统研究
打开文本图片集
中图分类号：TN249-34；TH712 文献标识码：A 文章编号：1004-373X（2025）16-0075-06
Research on frontmirror reference non-local interference angularmeasurement system
FANGZhenyuan，ZHANGBaowu，ZHULing，XUZijie，SUNYi，LUO Xianhuan （SchoolofMeasurementand Instrumentation，ChinaJiliangUniversity，Hangzhou31Oo18，China）
Abstract：Thenon-localinterferenceangular measuringsystemuses thelateraldisplacementof thecenterof theconcentric interferenceringgeneratedbyittodescribethechangeof themeasuredangle.Inalusiontotherelationshipbetweenthecenter lateraldisplacementdirectionandthedeflectiondirectionoftemeasuredangle，theefectivemeasurementrangeofthesystem， theresolutionof theinstrumentandotherisses，thevirtualsimulationandphysicalexperimentarecombined toconductindepthexplorationbytakingthestructuralsystemofthefront mirorreferencetypeastheobject.The theoreticalrelationship betweenthecenterlateraldisplacementoftheinterferenceconcentricringandthedeflectionofthemeasuredangleinthefront mirorreference-typeanglemeasurementsystemisestablished.The Zemaxvirtual simulationmodel isconstructed for the simulationverification.Thephysicalinstrumentwasbuiltfortesting.Theexperimentalresultsshowthatthelateraldirectionof theinterferencecenterofthefrontmirorreferencenon-localinterferenceanglemeasurementsystemisthesameasthemeasured angledeflectiondirection.Undertheconditionof givenparameters，themaximumefectiverangeof thesystemis90Omm，and theresolutioncan graduallydecreasewith the increase of the measurement range.The maximumresolutionatthe minimumrange is 0.0246′′ .The front miror reference non-local interferenceangle measurement system has the advantages of high measurement accuracy，wideapplicationscenarios，flexibleadjustmentofresolutionandmeasurementrangeaccording tomeasurementtasks， and can be competent for measurement of small angle and straightness.
Keywords：non-local interference;Tolanskyinterference;mirco-anglemeasurement；laserinterferencetechnique; interference angle measurement system;optical simulation
0 引言
微小角度测量是角度测量中的一个重要分支，在军事、航空航天以及精密加工等领域有着广泛应用[-2]。（剩余5432字）
