HUD镜面模具五轴定点加工方案研究及应用

打开文本图片集

中图分类号：TH162 文献标志码：A

Research and application on five-axis fixed-point machining scheme of HUD mirror mold

WANG Jianjun1，²，WANG Shuai³，MU Longtao†，²， ZHU Yutao1 ， ZHOU Xueyingl

（1. Shaanxi Polytechnic Institute，Xianyang 712OOo，Shaanxi，China; 2. Xianyang High-End CNC Machine Tool Key Components Engineering Technology Research Center，Xianyang 712OoO，Shaanxi，China;

3. Xi'an Jingdiao Precision Mechanical Engineering Co. Ltd.， Xi'an 71Oooo，Shaanxi， China）

Abstract： The high-definition display of the head-up display（HUD） relies on the machining accuracy of the mirror mold of the curved display cover. The conventional three-axis milling process based on common polycrystalline diamond（PCD） grinding is insufficient to ensure the machining quality of mirror molds. In this paper，a five-axis fixed-point machining technology for mirror mold is proposed，which uses the position cutting of the remote center static point to improve the linear speed of the actual cuttng of the tool and effectively improve the surface quality.

Key words： head-up display（HUD）；mirror mold; five-axis fixed-point machining； on-line measurement

1 抬头显示器（HUD）镜面模具加工 介绍

1.1 HUD产品介绍

HUD是一种先进的透明显示技术，可以图形或文字的形式直接在操作者的视野中呈现信息，无需用户移开目光或重新聚焦眼晴，进而有助于提高操作效率和作业安全性，该技术已广泛应用于航空、汽车、军事及其他高科技领域[1]。（剩余5411字）
