复兴号CR200J 型动车组电池自动加液装置研究

打开文本图片集

Study on Automatic Battery Refueling Device for Fuxing CR2ooJ EMU

LI Angyang

（Beijing Car Depot，China Railway Beijing Group Co.，Ltd.，Beijing 1Ooo39，China）

Abstract： With the upgrading of conventional passenger cars，Fuxing CR2ooJ EMU has gradually won the favour of passengers due to its fast and convenient characteristics and comfortable riding experience.The underframe battery is an emergency power source and power supply device for some electrical appliances on the carinemergency situations，and its good workingcondition is one of the elements to ensure the stable operation.The underframe battery of Fuxing CR2oOJ EMU is NI-MH battery. As this type of battery is increasingly used in motor cars，preventing and controling the safety risks，improving the maintenance quality，optimizing the maintenance technology and increasing the operational eficiency have become the main goals of improving the maintenance processes. The article describes the maintenance technology for the underframe battery of Fuxing CR20oJ EMU.Using the industrial automation technology，combined with MSP430 core control chip，MODBUS communication protocol and 3D printing technology，an automated battery refueling device has been developed to achieve the full automation of the process，improve the operation process，reduce the operation costs，improve the maintenance quality and reduce personal safety risks. Especially，the quality and eficiency of operation have been greatly improved，solving the basic problems of long operation time and cumbersome maintenance processes.

Keywords：EMU；automation;battery maintenance;refueling；device

1 研究背景

复兴号CR20OJ型电力动车组，是以 HXD1G 、HXD3G 型电力机车及25T型客车为原型设计的一款动力集中式电力动车组，最高运行时速为 160km/h 是我国既有电气化铁路中普速客车的必然进化方向[]。（剩余7126字）
