光声－超声双模态GIS气体层析成像技术研究

打开文本图片集

中图分类号：TP751 文献标志码：A 文章编号：1007-2683（2025）04-0134-09

Research on Photoacoustic-Ultrasound Dual-Modal GIS Gas Tomography Technology

TANG Bingnan'， ZHOU Yao’， WANG Anjing² （1. Lijiang Electric Power Supply Bureau，Yunnan Power Grid Co.，Ltd.，Lijiang 6741OO，China; 2.Anhui Institute of Optics and Precision Mechanics，Chinese Academy of Sciences，Hefei 23O031，China）

Abstract： Recently， environmentally friendly insulating gases represented by （ CF3 ） 2 CFCN have been widely used in high-voltage insulatedswitchgear（GIS）invariouscoutrisduetotheirlowglobalwarmingpotentialandozonefreecharacteristics.Duetothe colorlessandodorlessnatureofnvironmentallyfriendlyinsulatinggases，inordertosolvetheproblemofleakagedetectinand accuratelylocatetheleakagepointsof insulatinggases，aphotoacoustic-ultrasonicdual-modalGISgastomographytechnologyis proposed.BasedonphotoacoustictomographyandS-codingultrasonictomographytechnology，theadvantagesof thetwotomography methodsareintegrated，efectivelyimprovingthesignal-tonoiseratioofimagingresultshileensuringresolution，whichprovides technical support for the reliable detection of （CF3）2CFCN gas leakage. Compared with traditional methods，the optimized design methodimprovesthesigal-tonoieatioofthemagingesultsbymorethanOdB，andthsignal-toiseratiocanectivelyreflect the gas concentration，ultimately providing a new technical means for GIS insulation gas leakage detection.

Keywords：GIS insulation gas； photoacoustic tomography；circular array； S-coding；gas leakage

0 引言
