型钢混凝土剪力墙损伤演化与抗震性能优化研究

打开文本图片集

中图分类号：TU398 文献标志码：A 文章编号：1005-8249（2026）02-0148-10

DOI：10.19860/j.cnki.issn1005-8249.2026.02.023

Research on Damage Evolution and Seismic Performance Optimization of Steel Reinforced Concrete Shear Walls

LU Weiming'，WANG Zhibin²

（1. Xiamen City Huli District Construction Service Centre， Xiamen 361OOO， China; 2.College of Civil Engineering，Fuzhou University，Fuzhou 3501O8，China）

Abstract：Inorder toreveal thedamage evolution mechanismofstelreinforced concrete（SRC）shear wallunderearthquake actionadimprove itsseismicperformance，thispaper takes SRCshear wallinhigh-riseresidential structureastheresearch object，and carresoutlow-cyclerepeated loading test.During thetest，multi-source monitoring methodssuchas strain， displacement，crack，acoustic emisionand aceleration wereused tosystematicallytrack the mechanical response and damage accumulationcharacteristicsofthewallinthewholeprocessofelasticity，elastoplasticityandfailure.Theresultsshowthatthe middle and upper part of the wall （ 1.5～3.5m from the bottom of the wall ）is the damage concentration area. The maximum tensile and compressive strains of concrete are 1 950、 -2100με ，respectively. The strain of steel exceeds the yield threshold 0 ε±2000με ）. The maximum crack width is 0.55mm ，the interlayer displacement angle is 1/120 ，and the acoustic emission energy release is as high as 296.7mJ .Based on the damage distribution characteristics， optimization strategies such as sectional reinforcementof steel section，reinforcementratio improvementand concretestrength gradient designareproposed.

After optimization，the peak strain of wall concrete is reduced by 17% ，the crack width is reduced by nearly 50% ，the interlayer displacement angle is increased to 1/135，and the acoustic emission energy release is reduced by 47.7% ，which effectively improves the seismic performance and damage control ability of SRC shear wall.

Key words：stel-reinforced concrete；shear wall；damage acumulation；force analysis；monitoring plan；optimized desigr

0 引言

混凝土剪力墙作为一种重要的抗震结构构件，近年来在高层建筑和装配式结构中得到了广泛应用。（剩余12505字）
