电动汽车150kHz~30MHz电磁辐射发射仿真建模方法研究

打开文本图片集

【摘  要】本文在线束电流驱动线束感应产生电磁场的基础上，针对低频电磁辐射发射仿真过程中，近场观测点是否能够替代实际接收天线简化仿真流程以及线束建模方式的问题，通过仿真软件建立3种不同线束建模方式下实际接收天线和近场点两种求解电磁场方法的仿真模型来进行评估分析。

【关键词】电磁辐射发射；接收天线；近场观测点；线束建模方式

中图分类号：U463.67    文献标识码：A    文章编号：1003-8639（ 2023 ）10-0012-05

Research on Simulation Modeling Method of 150kHz～30MHz Electromagnetic

Radiation Emission of Electric Vehicle

ZENG Xia1，2，LI Xiaojiao1，2，CHENG Juan1，2，LEI Jianmei1，2，GAO Yangchun1，2

（1. State Key Laboratory of Vehicle NVH and Safety Technology，Chongqing 400039；

2. Chongqing Engineering Research Center for Automotive EMC Development，Chongqing 401122，China）

【Abstract】In this paper，based on the electromagnetic field produced by the wire beam induced by the current of the wire beam，the simulation of the emission of low frequency electromagnetic radiation is carried out，the problem of whether the near-field observation point can replace the actual receiving antenna to simplify the simulation process and the modeling method of the wire harness，the simulation models of the actual receiving antenna and the near-field point are established by the simulation software to evaluate and analyze the electromagnetic field.

【Key words】electromagnetic radiation emission；receiving antenna；near-field observation point；wire harness modeling
