基于LESO的永磁辅助同步磁阻电机无差拍控制

打开文本图片集

DOI：10.15938/j. emc.2025.08.011

中图分类号：TM352 文献标志码：A 文章编号：1007-449X（2025）08-0116-13

Deadbeat control of permanent magnet-assisted synchronous reluctance motor based on LESO

XU Aide¹， YU Yubang²，LIU Ruijie² （1.Information Science and Technology Colege，Dalian Maritime University，Dalian 116O26，China; 2. College of Marine Electrical Engineering，Dalian Maritime University，Dalian 116O26，China）

Abstract：To address the issue of parameter mismatch in traditional deadbeat predictive current control for permanent magnet-asisted synchronous reluctance motors （PMSynRM），which leads to current divergence and significant currnt fluctuations during operation，a deadbeat predictive current control algorithm based on a linear extended state observer （LESO） was proposed. Building upon the traditional deadbeat predictive current control algorithm，a linear extended state observer was introduced to estimate the total disturbance in real-time，and the estimated disturbance was fed back to the deadbeat controler for feedforward compensation. Based on the mathematical model of the PMSynRM，a mathematical model of the motor itself is established to simulate and validate the proposed algorithm.Finaly，experimental verification was conducted on a platform centered around the TMS32OF28335 controllr.Simulation and experimental results demonstrate that，compared to traditional deadbeat predictive current control，the proposed method exhibits better robustness and tracking accuracy under parameter mismatch conditions.

Keywords： permanent magnet-assisted synchronous reluctance motor；linear state observer; deadbeat predictive current control； robustness

0引言

随着现代工业不断地飞速发展，电机作为我国消耗巨大电能的设备，其耗电量占据整个现代工业耗电量的 60% ，因此一台具有高效节能低碳的电机就显得尤为重要，永磁同步电机（permanentmagnetsynchronousmotor，PMSM）因具有上述优点而成为如今电机研究的主流领域[1]。（剩余15243字）
