用于电压检测的交流场耦合激光器件结构设计和研究

打开文本图片集

关键词：交流场耦合；电网监测设备；激光二极管；非接触；电容器

中图分类号：TM835

文献标识码：A

DOI：10.14106/j.cnki.1001-2028.2025.1024

引用格式：王朋朋，谢彪，史宝冉，等. 用于电压检测的交流场耦合激光器件结构设计和研究[J]. 电子元件与材料， 2025， 44（2）： 165-170.

Reference format： WANG Pengpeng， XIE Biao， SHI Baoran， et al. Structure design and research on lasers devices with AC field coupling for voltage testing [J]. Electronic Components and Materials， 2025， 44（2）： 165-170.

Structure design and research on lasers devices with AC field coupling

for voltage testing

WANG Pengpeng 1， XIE Biao 1， SHI Baoran 1， WU Chaoxing 1， 2

（1.College of Physics and Information Engineering，Fuzhou University，Fuzhou 350108，China；2.  Fujian Science &

Technology Innovation Laboratory for Optoelectronic Information of China， Fuzhou 350108，China）

Abstract：  As an indispensable and fundamental facility in modern society， power grid emphasizes the utmost important factors of continuity and safety operation. To ensure stable operation and promote rapid development of smart grid， it is particularly important to implement real-time monitoring of the power grid. Here an AC field-coupled laser device was proposed for voltage detection. The device has an electrode/laser diode/electrode structure， which enables non-contact monitoring by converting the information of the high-voltage lines into modulated laser pulses. Experimental results show that the optimal linear fitting R 2 is 0.99364 for the peak intensity of the output laser waveform in the proposed laser device structure， which confirms it can accurately extract real-time voltage variations on the HV line. The laser intensity output waveform and the voltage waveform of the HV test bar have strong correlation both in time and frequency domains， which enable rapid capture of the voltage variation and provide instantaneous response. As a new online monitoring device for the high-voltage lines， this laser structure can provide a new impetus for the development of power grid technology.

Keywords：AC field coupling; grid monitoring equipment; laser diode; non-contact; capacitor

电力系统的高压线路（High Voltage Line， HV Line）监测技术为了满足现代社会对高电能质量和电网精确监控的需求，经历了显著的发展历程 [1-5]。（剩余6051字）
