一种多层扭曲金字塔型电磁波吸收器

打开文本图片集

关键词：电磁波吸收；多层扭曲结构；金字塔吸波器；宽带吸收

中图分类号： TN61

文献标识码：A

DOI：10.14106/j.cnki.1001-2028.2025.1403

引用格式：陆勤龙，王林杰，宾峰.一种多层扭曲金字塔型电磁波吸收器 [J]. 电子元件与材料， 2025，44（2）： 142-146.

Reference format： LU Qinlong，WANG Linjie，BIN Feng. A multi-layer twisted pyramid electromagnetic wave absorber [J]. Electronic Components and Materials， 2025， 44（2）： 142-146.

A multi-layer twisted pyramid electromagnetic wave absorber

LU Qinlong 1， 2，WANG Linjie 3，BIN Feng 1， 2

（1.CETC No.16 Research Institute， Hefei 230043， China; 2. CETC Key Laboratory of Superconducting and

Electronic Technologies， Hefei 230043， China; 3. Optoelectronic Technology Research Institute， Hefei University of

Technology， Hefei 230091， China）

Abstract： This article proposed a multi-layer twisted pyramid absorber （MTPA） for electromagnetic waves. By introducing metal square patches and adjusting the arrangement and rotation angle of the metal patches， ultra-wideband absorption was achieved in the frequency bands of 6.95-24.25 GHz and 26.51-38.81 GHz. Compared with traditional pyramid absorbers， MTPA can not only improve absorption performance in the low-frequency region， but also introduce an additional absorption band from 26.51 to 38.81 GHz. To study the widening mechanism of the absorption bandwidth of the twisted structures， a simulation was carried out on the structure， and the third-order mode magnetic field distribution of the MTPA absorbers and traditional absorbers was compared and analyzed in the absorption frequency band. It is found that the resonance frequency of the third-order mode in the proposed MTPA is much lower than that of traditional pyramid absorbers， causing the resonance frequency of the third-order mode to redshift and ultimately intersect with the resonance frequency band of the fundamental mode， thus broadening broaden the absorption bandwidth. This study provides new ideas and references for the design of ultra-wideband absorbers.

Keywords： electromagnetic wave absorption; multilayer-twisted structure; pyramid absorber; wideband absorption

电磁超材料吸收器 [1-3]（Metamaterial Absorbers， MAs）在现代电磁吸收问题中发挥着重要作用。（剩余7525字）
