层间距宽化的MoS 2纳米片修饰rGO作为锂硫电池催化材料

打开文本图片集

关键词：锂硫电池；二硫化钼；石墨烯；中间层；层间距宽化

中图分类号： TM912

文献标识码：A

DOI：1014106/jcnki1001-202820251372

引用格式：黄浩洋， 夏艳婷， 许俊. 层间距宽化的MoS 2纳米片修饰rGO作为锂硫电池催化材料 [J]. 电子元件与材料， 2025， 44（2）： 127-134

Reference format： HUANG Haoyang， XIA Yanting， XU Jun. Widely spaced MoS2 nanosheets decorated rGO as catalytic materials for lithium-sulfur batteries [J]. Electronic Components and Materials， 2025， 44（2）： 127-134

Widely spaced MoS2 nanosheets decorated rGO as catalytic materials

for lithium-sulfur batteries

HUANG Haoyang， XIA Yanting， XU Jun

（School of Microelectronics， Hefei University of Technology， Hefei 230009， China）

Abstract： Lithium-sulfur batteries （LSBs） have attracted significant attention due to their high theoretical specific capacity and energy density. However， the severe shuttle effect of lithium polysulfides （LiPSs） and slow redox kinetics limit their commercial application. To address these challenges， a widely spaced MoS2 nanosheets grown on reduced graphene oxide （rGO/IE-MoS2） was designed and used as an intermediate layer coating materials for LSBs to inhibit the shuttle effect of LiPSs. The three-dimensional network structure of rGO and the two-dimensional layered MoS2 nanosheets can enhance the electronic conductivity and Li+ migration rate of the materials， and provide rich catalytically active sites for effective LiPSs adsorption and conversion. The intercalation of carbon expands the interlayer spacing of the MoS2 nanosheets to 103 nm， which effectively reduces the transport barrier for Li + ions. Batteries assembled with rGO/IE-MoS2/CFP as the intermediate layer exhibit excellent rate performance and cycling stability， which have a reversible capacity of 1202 mAh·g -1 at 01C， a capacity fading rate of 0078% per cycle over 500 cycles at 1C， and a high-rate performance of up to 789 mAh·g -1 at 4C. This work provides new insights into the development of catalytic materials for lithium-sulfur batteries.

Keywords： lithium-sulfur batteries; molybdenum sulfide; graphene; interlayer; interlayer expansion

自从1991年索尼公司宣布锂离子电池实现商业化以来，锂离子电池凭借其优越的性能迅速发展。（剩余11966字）
