软硬混编预制体窄缝通道连续碳纤维束引纬系统的设计及实验验证

打开文本图片集

中图分类号：TB332

DOI：10.3969/j.issn.1004-132X.2025.07.014 开放科学（资源服务）标识码（OSID）：

Design and Experimental Verification of a Narrow-channel Continuous Carbon Fiber Tow Weft Insertion System for Soft-Hard Blended Preforms

XING Lipeng1，² DONG Jiuzhi1，2 * CHEN Yunjun³Li Rui1，²JIANG Xiuming1，2 1.School of Mechanical Engineering，Tiangong University，Tianjin，300387 2.Advanced Mechatronics Equipment Technology Tianjin Area Major Laboratory， Tiangong University，Tianjin，300387 3.School of Control Science and Engineering，Tiangong University，Tianjin，300387

Abstract： To address the issues of high labor intensity and low forming eficiency caused by manual weft insertion in narrow channels during the forming processes of soft-hard blended preforms，an automated weft insertion system was developed based on an S-shaped trajectory of continuous carbon fiber tow.The formation mechanism of the S-shaped trajectory was analyzed to establish the synergistic relationship between carbon fiber bundle positioning and coordinated multi-mechanism motions.A system architecture was designed，with the weft delivery mechanisms， electronic weft insertion mechanisms and post-insertion control mechanisms as the core components. Prototype experiments demonstrate that the system achieves continuous and stable weft insertion in narrow channels at a rate of 12.5 picks per minute.

Key words： soft-hard blended preform；narrow-channel weft insertion； continuous carbon fiber tow;S-shaped trajectory;weft insertion system

0 引言

碳/碳（C/C）复合材料因其优异的抗烧蚀、抗热冲击性和耐摩擦性能而广泛用于航天热结构和热防护部件[1-4]。（剩余12133字）
