人参拔秧机拔秧轮的结构设计与分析

打开文本图片集

中图分类号：S223 文献标识码：A 文章编号：2095-2953（2025）10-0031-07

Abstract：Ginseng stems and seedlings are of high economicand medicinal value.To addressthe problems of timeconsuming，labor-intensive and high economic cost of existing manual seedling puling in China，a new type of seedling puller is intended to be designed.This paper conducts a preliminary design of the key component，i.e.，the sedling pulling wheel.According to the height of ginseng Varieties planted in Northeast China at the present stage，， as well as the planting interval and densityof ginseng，the diameter oftheseedling puling wheel is determined tobe 600mm and the length to be 2m . The three-dimensional modeling of the seedling pulling wheel is carried out using SolidWorkssoftware.In order to improve the unloading eficiencyand the applicabilityof the ginseng seedling puller，and in order to facilitate the operation on some ginseng stems and seedlings with longer length and deeper roots， the motion trajectory of the seedling pulling wheel is analyzed，and it is found that the ratio λ of its circumferential speed to the forward speed has an important influence on its operation.The three-dimensional model of the seedling puling wheel is imported into ADAMS for kinematic analysis，and the displacement and speed curves of the seedling pulling wheel under different seedling pulling speed ratios λ are measured.Finally，it is found that the value range of the seedling pulling speed ratio λ should be 1<λ⩽1.65 . When λ is less than or equal to 1， the seedling pulling tooth rolerhas no backward displacement relativeto the groundandfails to forma backwardacting force，which can't achieve the purpose of improving unloading efficiency and applicability. When λ is greater than 1.65，the motiontrajectories of multiple tooth rollers of the seedling pulling wheel intersect，which may cause damage to ginseng stems and seedlings.

Key words： ginseng；seedling puling；seedling pulling wheel；ADAMS； kinematic simulation； seedling puling speed ratio

人参是我国特产珍贵药材之一，据《本草纲目》记载，人参具有主补五脏、安精神、定魂魄、正惊悸、除邪气、明目、开心益智的功效，被誉为东北三宝之首[1-3]，入药部份主要为根和须，有着悠久的历史[4-7]。（剩余6352字）
