人造板饰面卷材裁切装置设计及其性能研究

打开文本图片集

中图分类号：S777 文献标识码：A 文章编号：2095-2953（2025）06-0047-08

Design and Performance Study of a Wood-Based Panel Decorative Roll Cutting Device

HUANG Hui， ZHANG Sen， ZHANG Jia-cheng，LIU Yu-tong， ZHAO Hui * （CollegeofMechanicalandElectricalEnginering，NortheastForestry University，Harbin Heilongiang150o40，China）

Abstract：To addressthe issues of precision and eficiency in the cuting process of wood-based panel decorative rolls，this study designeda roll cutting device based ona crank-slider mechanism and analyzed itsperformance.The working principle and power transmision requirementsof the cutting device wereevaluated，withan ecentric whel selected asthe crank.Rigid-body dynamics simulations were conducted to verifythe feasibilityof the mechanism's motion.Aditionally，explicit dynamic simulations were performed to model the cutting process，focusing on the stress，strain，and shear force distribution in therollmaterial.Thesimulationresults demonstrate thatthe speedtime and displacement-time curves of the upper cutter were consistent with theoretical requirements，and the motion trajectory was stable. In the cutting region，the maximum equivalent stressreached 10 MPa，the maximum equivalent strain was O.O83，and the maximum shear stress was 5.77MPa ，approaching the material's shear yield strength and successfullyachieving material shearing.Theresultsverifytherationalityof thecuting device designand thereliabilityof its performance，providing technical support for improving the cutting eficiencyand precision of wood-based panel decorative rolls and ofering valuable references for the optimization of similar cutting devices.

Key words：wood-based panel decorative roll； cuting device;；crank-slider mechanism；rigid body dynamics； ex-plicit dynamics

人造板（Wood-basedpanel）是一种以木材或非木质植物纤维为原料加工制成的板材，具有资源利用率高、性能可定制等特点，广泛应用于家具制造、室内装饰和建筑行业[1]。（剩余7962字）
