伴生气掺氢条件下KSM型静态混合器参数优化

打开文本图片集

中图分类号：TB9;TE832 文献标志码：A 文章编号：1674-5124（2025）07-0087-08

Abstract： The Kenics static mixer can promote the mixing of associated gas and hydrogen，and its structural parameters need to be further optimized in order to ensure the combustion safety of the mixed gas.Therefore， orthogonal experiments were designed and computational fluid dynamics software Fluent was used to simulate the effects of the number of diversion components，component distortionangle and vertical angle between diversion components on the mixing uniformity of Kenics static mixer（KSM），and the optimal structural parameters were obtained. The results show that the three factors have great influence on the mixing uniformity，the influence magnitude is： the number and length of components > the torsion angle of components > the vertical angle of components. The mixing non-uniformity decreases with the increase of the number of diversion components and the increase of the component torsion angle，and increases with the increase of the verticalangle of diversion components，showing a trend of first rising and then decreasing.The optimal structural parameters of the mixer are as follows： when the number and length ofthe diversion group are12×30mm ，the torsion angle of the component is 270∘ ，and the vertical angle of the componentis 90∘ ，the mixing non-uniformity is the lowest 0.23% .The research results can provide technical reference for the structure design of static mixer with high mixing uniformity in the background of hydrogen mixing.

Keywords： KSMstatic mixer;associated gas blended hydrogen;gas mixing; numerical simulation; orthogonal experimental; structure optimization

0 引言

在当今世界化石燃料供应不足的背景下，氢能因其清洁环保和可持续利用等优势成为新的研究热点，发展氢能也是实现碳中和能源战略目标的重要手段[1-2]。（剩余10553字）
