LTCF变压器绕组性能提升分析

  • 打印
  • 收藏
收藏成功


打开文本图片集

关键词:LTCF;变压器绕组;分层结构;耦合系数;损耗

中图分类号: TM402

文献标识码:A

DOI:10.14106/j.cnki.1001-2028.2025.1534

引用格式:张泰岳, 邢孟江, 杨圆圆, 等. LTCF变压器绕组性能提升分析 [J]. 电子元件与材料, 2025, 44(3): 272-277.

Reference format: ZHANG Taiyue, XING Mengjiang, YANG Yuanyuan, et al. Analysis of performance enhancement of LTCF transformer windings [J]. Electronic Components and Materials, 2025, 44(3): 272-277.

Analysis of performance enhancement of LTCF transformer windings

ZHANG Taiyue 1, XING Mengjiang 1, 2, YANG Yuanyuan 2, LI Xiaozhen 3

(1. School of Electronic Science and Engineering, University of Electronic Science and Technology of China, Chengdu

611731, China; 2. Yangtze Delta Region Institute (Huzhou), University of Electronic Science and Technology of China,

Huzhou 310031, Zhejiang Province, China; 3. Fujian Provincial Key Laboratory of Modern Communication and Beidou

Positioning Technology, Quanzhou College of Information Engineering, Quanzhou 362000, Fujian Province, China)

Abstract: To address the issues of excessive volume, low coupling coefficient, and high losses in the winding design of Low Temperature Co-fired Ferrite (LTCF) planar transformer, this study systematically optimizes critical structural parameters within the LTCF winding configuration to achieve the performance enhancements. The LTCF planar transformer winding structure was modeled and subjected to the electromagnetic simulation, and the results indicate that the circular layout demonstrates the best performance among various layout schemes. By analyzing the key factors which affects the transformer efficiency, it is concluded that adopting a flattened winding structure could improve the transformer performance. Furthermore, after an in-depth analysis of the multilayer winding structures, a novel winding layering structure was proposed, effetively reducing the overall volume by about 20% compared to traditonal structures. By comparing the simulation results of different winding structures under series and parallel configurations, it is found that with this new winding layering structure, the coupling coefficient could be increased by up to 41% and the losses could be reduced by up to 40%.

Keywords: LTCF; transformer winding; hierarchical structure; coupling coefficient; loss

伴随着通信设备、计算机、家电、新能源汽车及物联网等新兴领域能源效率需求的提升和设备小型化发展的趋势,变压器作为电路系统中体积和重量占比最大的器件,变压器小型化的需求日益增加 [1]。(剩余6142字)
