基于LTCC工艺的高耦合平面变压器仿真设计

打开文本图片集

关键词：LTCC工艺；平面变压器；耦合效率；仿真

中图分类号：TM433

文献标识码：A

DOI：10.14106/j.cnki.1001-2028.2025.1461

引用格式：黎楚明， 李元勋， 李馥余. 基于LTCC工艺的高耦合平面变压器仿真设计 [J]. 电子元件与材料， 2025， 44（3）： 265-271.

Reference format： LI Chuming， LI Yuanxun， LI Fuyu. Simulation and design of a high-coupling planar transformer based on LTCC technology[J]. Electronic Components and Materials， 2025， 44（3）： 265-271.

Simulation and design of a high-coupling planar transformer based

on LTCC technology

LI Chuming 1，2， LI Yuanxun 1，2， LI Fuyu 1，2，3

（1.School of Electronic Science and Engineering， University of Electronic Science and Technology of China， Chengdu

610054， China; 2.State Key Laboratory of Electronic Thin Films and Integrated Devices， University of Electronic Science

and Technology of China， Chengdu 610054， China; 3.Tianfu Jiangxi Laboratory， Chengdu 610054， China）

Abstract： This study employed the Low-Temperature Co-fired Ceramic （LTCC） technology to develop a miniaturized， high-coupling planar transformer. To address the low coupling efficiency in existing LTCC planar transformers， an innovative design was proposed. The primary and secondary coils were placed on the same plane， and a non-magnetic dielectric layer was added between the primary and secondary coils to enhance the coupling coefficient. Additionally， the structural parameters were simulated to understand their effect on the coupling coefficient. The simulation results demonstrate that the coupling coefficient of the proposed LTCC planar transformer is significantly better than that of traditional structures， with a simulated coupling coefficient value of over 0.9. This design provides a valuable reference for the future development of LTCC planar transformers with high coupling efficiency.

Keywords： LTCC process; planar transformer; coupling efficiency; simulation

低温共烧多层陶瓷技术（Low Temperature Co-Fired Ceramic， LTCC）作为一种先进的集成技术，近年来已广泛应用于无源器件的集成，国内外许多学者对其展开了研究 [1-9]。（剩余7520字）
