泵站正向进水前池水流特性与扩散角度优化

打开文本图片集

中图分类号：TV675 文献标识码：A 文章编号：1001-9235（2025）07-0122-10

Abstract：Toaddressisuesarisingfromchaoticwaterflowduetounreasonablepumpingstationoperationandinsuficienforebay design，thisstudytooktheYanhuangdingpumpingstationasatypicalcase.NumericalsimulationsusingFLUENTsoftwarewere conducted toexaminediferentforebaypaternsbasedontheRealizableturbulence modelandtheEulerianmultiphaseflowmodel. Theinfluencesofdiferentdifusionanglesanddiffrentumberofoperatingpumpingstatinsontheflowfieldstrucureinthefrebay were expounded. The results show that： ① As the diffusion angle increases，the number of vortices in the forebay flow rises from one to two.At diffusion angles of 25∘ and 30∘ ，the vortex area occupies less of the forebay inflow，resulting in a more stable flow field. ② （204号 Reducing thenumberofoperatingpumpingstationsfromfivetotwodecreases thevortexareaintheforebafrom31.42mto0.15 m2 ，withoptimalforebay flow achieved when operating pumping stations 3# and4#.Theresearch resultscan providereferenceand guidance for the design and renovation of similar pumping stations.

Keywords： pumping station; FLUENT; forward forebay; physical experiment; numerical simulation前池作为泵站进水结构的一个核心构成部分， 对于调控水流状态具有至关重要的作用。（剩余8313字）
