基于改进SSD算法的铣刀前刀刃抗破损设计方法讨论

打开文本图片集

Anti-breakage design of industrial milling cutter edge based on improved SSD algorithm

XU Chun¹，LIU Tao²*， ZHAN Zhimin²， ZHANG Suipeng²，LIU Qifeng² （1. Nanyang Hanye Special Steel Co. Ltd.，Nanyang 473ooo， Henan China; 2. University of Science & Technology Beijing Institute of Engineering Technology，Beijing，China）

Abstract： The machining field environment of industrial milling cutter is complex，and the traditional machining method can not accurately control the tool edge parameters in visual inspection，which leads to the inability to ensure good anti-breakage performance of milling cutter in subsequent cutting. Therefore，an anti-breakage method of industrial milling cutter edge based on improved SSD algorithm is designed. In the design process， according to the single-tooth milling situation of industrial milling cutter， the time interval controlled by the program is calculated， and the sagittl diameter value corresponding to cutter tooth cutting is obtained to calculate the length of cutting edge. The overlapping form of micro-teeth of industrial milling cutter is optimized， and the small parameters are determined. Finally，an improved SSD algorithm is introduced to detect the damage of cutter edge and parameters.

The results of the edge breakage resistance test show that under the same test environment， the severe breakage rate of the tool obtained by the design method is greatly reduced，which shows that the breakage resistance performance has been improved and verifies the effectiveness of the method.

Key words： improva SSD algorithm； industrial miling cutter;tool edge; resistance to breakage

0 引言

机械加工自动化水平随着科技的进步不断提高，为了保证在机械加工过程中能够充分发挥机床设备的控制作用，在保证产品生产质量的同时，需要尽量将机床的切削过程进行优化[1]。（剩余8731字）
