链勺式半夏精密排种器设计与仿真分析

打开文本图片集

中图分类号：TP242;S776 文献标识码：A 文章编号：2095-2953（2025）03-0048-08

Design and Simulation Analysis of a Chain-spoon Precision Seeder for Pinellia ternata

CAO Meng， FENG Li * ， ZHENG Gao-yin， HU Feng （CollegeofMechanicalandElectricalEngineering，NortheastForestryUniversity，HarbinHeilongjiang15O6，China）

Abstract：Toaddress the chalenges posed bythe iregular shape，large size，and thin seedcoat of Pinellia ternata seds，which lead to dificulties in seedflling and clearing，and being damaged easily during sowing，a chain-spoon precisio seed metering device was designed.The physical propertiesof Pinelia ternata seeds during the sowing period were measured to guide the design processKey parameters of the metering device were determined through theoretical analysis，and the seed filing process was simulated using DEM-MBD coupled simulation.A response surface model was establishedusing Design-Expert toevaluate the effects of the drive sprocket speedand the ratio of seed stirring toseed metering speed on the seed filing qualification indexand the missed filing index.Theresults showed that both the drive sprocket speed and the speed ratio between the seed stirring and metering devices were crucial factors affecting the seed filling performance. When the drive sprocket speed was 98.77r/min and the seed stirringto-metering speed ratio was O.53， the seed filling qualification index reached 94.220% ，and the missed filling index was 2.29% ，meeting the sowing requirements for Pinellia ternata seeds.

Key words：Pinellia ternata；chain-scoop type；seed metering device；DEM-MBD

半夏具有燥湿化痰和降逆止呕的功效，其干燥块茎被广泛应用于中药中，具有十分重要的药用价值[1]。（剩余8107字）
