基于酸掺杂的PANIPET材料的结构调控及其导电性

打开文本图片集

关键词：聚苯胺/聚酯复合织物；掺杂酸；分子结构；导电性；纳米发电机中图分类号：TM912.9;TQ152 文献标志码：A 文章编号：1671-024X（2025）03-0049-06

Structural control of PANI/PET materials based on acid doping and its conductivity

JIN Xin1，2，，LIU Xiaodong1，2 （1.School of Material ScienceandEngineering，Tiangong University，Tianjin ，China；2.ResearchCenterfor Future Textile Technology，Tiangong University，Tianjin 3Oo387，China）

Abstract：Toimprove theconductivityof polyaniline/polyester（PANI/PET）compositeconductive fabrics，diferentacid doping methods were used to regulate the molecular structure of PANI.PANI was polymerized in situ on the surface of PET fibers to prepare PANI/PETcomposite fabrics.The effect of doping acid types on the structure and conductivity of PANI/PETmaterials was analyzed using SEM，FTIR，XRD，and conductivity testing; PANI/PET composite conductive fabric wasassembled with metal Al and Cu film electrodes to prepare Schottky type nanogenerators and their electrical output performance was investigated.The results indicate that the type of doping acidsignificantlyafectsthe benzoquinone structure ratio，molecular chainregularity，and interplanarspacing of PANI; PTSA doped PANI exhibits the highestbenzene/quinone structure ratio （2.16），optimal interplanar spacing （0.343nm ），and highest crystallinity（ 46.16% ），resulting in the best conductivity performance （O.65 S/m）; The Schottky nanogenerator prepared based on PTSA doped PANI/PET composite material exhibits excellent electrical output performance，with an open circuit voltage of 0.973V and a short-circuit current of 327.19μA ， furtherverifying the excellent conductivityof the material.

KeyWords：PANI/PETfabric；dopant acid;molecular structure；electrical conductivity；nanogenerator

随着可穿戴电子设备的快速发展，对柔性高导电性材料的需求日益增长。（剩余11173字）
