提效降损型调压控制器电源设计

打开文本图片集

摘  要：针对有载调压控制器客观存在的可靠供电等问题，该文设计一种基于双输入、双输出及双后备的低功耗电源管理模块。该模块可实现不同电源之间的无缝切换和双后备储能，确保有载调压控制器供电系统的安全、可靠、低碳和节能，从而提高供电电压的质量。

关键词：有载调压控制器；无缝切换；电源管理模块；电路设计；模块设计

中图分类号：TN86       文献标志码：A           文章编号：2095-2945（2023）01-0124-04

Abstract： According to many problems of on-load voltage regulating transformer controller， a low power onload voltage regulating controller based double input， double output and double backup is designed. This module can realize the seamless switching between different power sources and double backup energy storage， to ensure the safety， reliability， low carbon and energy saving of the on-load voltage regulating controller power supply system， so as to improve the quality of the power supply voltage.

Keywords： on-load voltage regulator controller; seamless switch; power management module; circuit design; module design

电压稳定性是电能质量的重要指标之一。（剩余4271字）
