镍阳极板扭线穿棒设备的研发与应用

打开文本图片集

中图分类号：TF815 文献标志码：B 文章编号：1004-4345（2025）02-0029-05

Research and Application of Twisted-Wire Threading Rod Equipment for thePreparationofNickel AnodePlate

HAN Lizhong， FU Shouguo，LYU Dianqiang， ZHANG Jintao， CHU Liangji （Yantai Tongtai Metallurgical EquipmentManufacturing Co.，Ltd.，Yantai，Shandong 264OO2，China）

AbstractAfullautomatictwisted-wire threadingrodequipmentfornickelanodeplatewasdesignedanddevelopedtoaddress theproblemsofloweficiencyhighsafetyhazards，ndunstableproductqualityinmanualoperationduringthepreparationof nickel anode plates.Theequipmentconsistsofcoreunitssuchaspositioningandfeding，automatictwisting，automaticrodthreadingand plateselection&disarging.ItdoptsaintellgensotingssteandROFEdistrbutedcontrolframework，ntegateddamic weighing，3D visual positioning，and mechanical arm linkage technology，and achieves the processobjectives of 90∘（±1∘） precise twistingofcopperwireandcoaxialthreadingofconductiverods（eror≤±.5mm）throughamulti-unitcolaborativecontrol architecture and high-precision servo drive technology.

Keywordsnickel electrolysis;nickelanodeplate；automationequipment;servodrive;twistedwire threadingrod;inteligent sorting

1研发背景

镍阳极板作为不锈钢、动力电池及高温合金材料等高端产品的原料，其电解工艺过程控制的好坏直接影响电解效率与产品合格率。（剩余5542字）
