面向空间目标广域探测的大视场宽 光谱光学系统设计

打开文本图片集

中图分类号：D590.35D510.40 文献标志码：A doi：10.37188/CO.2024-0198 CSTR：32171.14.CO.2024-0198

Design of optical system with wide field of view， broad spectral range for space target detection

MU Shuai-wei 1，2 ， WU Hong-bo1， ZHANG Xin1，MA Lin1， YAN Lei1， TAN Shuang-long1

（1. Changchun Institute ofOptics，Fine Mechanics and Physics， Chinese Academy of Sciences， Changchun 130033， China; 2.University of Chinese Academy ofScience，Beijing l0oo49， China） * Corresponding author，E-mail： 15567408408@126.com

Abstract： To achieve wide-area detection of space targets， we design an optical system with a broad spectrum range （ 400～1000nm ）， a large field of view （61∘） ）， a smallF-number （1.38）， and low distortion. This optical system is capable of detecting space targets with a magnitude of 6， enabling wide-area detection for space targets. Initially，a mapping between the radiation model of space target detection and the optical system parameters is established. The optical design is then theoretically analyzed using a reverse telephoto layout as the initial design configuration. The design is optimized to balance and correct the severe chromatic aberration resulting from the large field of view and wide spectral range， while improving enclosed energy and considering the roundness of scattered spots.Finally，The detection capability is verified through space optical simulation experiment and physical experiment. The results show that the optical system meets the wide-area detection requirements for space targets with a magnitude of 6.The overall design of the optical system is reasonable and compact， meeting the requirements of wide-area detection of space targets.

Key Words： space target; wide-area detection; optical system design; large field of view; broad spectrum

1引言

随着科学技术的发展，人们对太空的探索愈加频繁，数以千计的航天设备被发射向太空。（剩余14370字）
