新型永磁体半插入式转子高速永磁电机的应力与损耗分析

打开文本图片集

关键词：高速永磁电机；半插式永磁体；转子强度；应力分析；损耗；结构优化DOI：10.15938/j.emc.2025.09.006中图分类号：TM351 文献标志码：A 文章编号：1007-449X（2025）09-0061-11

Abstract ：A new type of inserted permanent magnet motor was proposed to address the problems of excessive stressand high losses in the rotor of high-speed permanent magnet motors，in order to protect the permanent magnet structure and reduce heat generation. Firstly，based on the strength requirements of each part of the rotor under diffrent operating conditions，an analytical model and a three-dimensional finite element model of the motor rotor were established to analyze the changes in rotor stress under different operating conditions，different sheath thicknesses，different interference amounts，and different insertion depths of permanent magnets. The sheath thicknessand interference amount were determined according to the allowable stress of each part of the material，and the feasible range of insertion depth was preliminarily determined.Based on this，the influence of diferent insertion depths on the iron loss and rotor eddy current loss of the motor was studied to determine the final insertion depth.This new rotor structure can improve rotor strength，reduce sheath thickness，and effectively reduce eddy current losses，which has reference significance for the lightweight development of high-speed permanent magnet motors.

Keywords ：high-speed permanent magnet motor; inserted permanent magnet; rotor strength ; stress analysis；loss； structure optimization

0引言

高速永磁电机因其具有高效率、体积小、响应速度快、可靠性高等优点，被广泛运用在高速磨床、新能源汽车等多个领域中，具有十分广泛的应用前景。（剩余14709字）
