基于数字模型的平衡衔铁式继电器接触系统质量一致性优化设计

打开文本图片集

关键词：平衡衔铁式；接触系统；数字模型；质量一致性

中图分类号：TM581文献标志码：A文章编号：2095-8188（2025）07-0001-08

Abstract：Themain failuremodeof balancedarmaturerelays during operationiscontact ablation in the contact system，which iscaused bylarge dispersionin the pull-inspeedduring therelay’spullin process. Excessively highpull-inspeed canlead tocontactbounce，while excessivelylow pull-inspeed can result in poor pullin.Taking a certain type of productas the research object，a method for consistent parameter design and tolerancedesign basedondigital models isproposed.Byestablishingan electromagnetic-mechanical co-simulation model of the entire machine，the influence laws of key parameters suchas contact gapand initial pressre on the pull-in speed are analyzed.After optimization，the average pull-in speed is reduced to 0.3224ms ，and the standard deviation isdecreased by 17.9% .Through tolerance design，the standard deviationis further reduced by （204号 34.3% ．The tests show that the proposed method can effectively suppress contact bounce and arcing phenomena， and improve the product quality consistency.

Keywords：balanced armature；contact system；digital model；quality consistency

0 引言

电子元器件是高端装备现代化、信息化、智能化的基础，也是重要的战略性资源，其质量一致性直接影响高端装备研制和服役的进程[1-8]。（剩余6432字）
