全塑料3倍全动型变焦镜头设计

打开文本图片集

Abstract： To address the increasing demand for compact，high-performance zoom lenses in consumer electronics，this paper presents the design of an all-plastic 3× continuous zoom lens featuring fully movable components.An all-movable zoom structure is employed，wherein all lens groups are mobile to optimize both zoom range and image quality.Q-type aspheres are utilized to enhance optical performance， while plastic materials serve to reduce manufacturing costs. Optical properties are assigned to each surface using LightTools，and ghost image analysis is performed via ray tracing. The optimized lens achieves a 3× zoom range from 22. 72mm to 68.16mm with an F-number of 4.5 and a total optical length under 68 mm.At object distances of 1O，1，and 0.2m ，the diffraction MTF exceeds O.3at 80lp/mm and 0.22 at 160lp/mm across all fields of view at various zoom positions，ensuring high-resolution imaging. The cam curve is smooth and free of inflection points. Ghost image analysis indicates that the peak irradiance of ghost images formed by all surface combinations remains below 0.0122% of the main image's peak irradiance，demonstrating negligible impact on system performance. The proposed all-plastic 3× all-movable zoom lens exhibits excellent optical performance，compactness，and manufacturability，offering a valuable technical reference for the design of high-performance，miniaturized zoom lenses.

Key words： optical design； al-movable zoom；all-plastic lens；Q-type aspheres；cam curve of zoom;ghost image analysis

1引言

近年来，紧凑型变焦光学系统在相机镜头、安防监控、医疗诊断等领域都有广泛应用[1-2]。（剩余13397字）
