混合磨料柔性抛光工具加工碳化钨合金性能研究

打开文本图片集

中图分类号：TH161;TG58 文献标志码：A 文章编号：2097-3853（2025）04-0402-07

Study on performance of tungsten carbide alloy processed by mixed abrasive flexible polishing tools

ZHAO Jiachen1，XU Yongchao’，HE Jiafeng¹，CHEN Bingsan²，SHI Yang'，WANG Qianting 3 （2 （1.School of Materials Science and Engineering，Fujian University of Technology，Fuzhou 35O118，China; 2.School of Mechanical and Automotive Engineering，Fujian Universityof Technology，Fuzhou 350118，China; 3.School of Materials Science and Engineering，Xiamen University of Technology，Xiamen 361024，China）

Abstract： Semi-solidified flexible polishing discs are prepared for polishing tungsten carbide alloys by using SiO2 ，diamond，and SiO 2 /diamond mixed abrasives，and deionized water is used as the polishing solution to avoid contamination.Based on the mechanical properties of the flexible substrate of polishing discs，the polishing performance of tungsten carbide specimens with diffrent kinds of abrasives was investigated，and he surface quality after processing was analyzed.Results show that：after the use of a mixed abrasive disc polishing with wSiO2/wdiamond=2：3 ， the surface roughness of the sample is reduced to 0.007μm ， and that is a reduction of 96% ，the surface deep scratches and pits are effectively removed，and the PV value is 0.17μm Compared with the sample surface after the use of a single SiO2 and diamond abrasive disc polishing，PV values are reduced by 81% and 64% ，respectively.

Keywords： tungsten aloy； flexible polishing；semi-fixed polishing discs； surface morphology； mixed abrasives

在钨合金抛光过程中，磨料是影响加工后工件表面质量的关键因素，钨合金抛光方法所使用的磨料可分为游离磨料与固结磨料[1-4]。（剩余6705字）
