大型快速紧锁机构多领域仿真和试验分析

打开文本图片集

DOI：10.15938/j. emc.2025.05.001

中图分类号：TM341;TP391.9 文献标志码：A 文章编号：1007-449X（2025）05-0001-11

Multi-domain simulation and test analysis of large-scale fast-locking mechanism

ZHI Yajie1²，RUI Wanzhi²，XU Yan²，KONG Wubin1 （1.SchoolofElectricalandElectronic Engineering，Huazhong UniversityofScienceandTechnology，Wuhan430o，China; 2.National Key Laboratoryof Electromagnetic Energy，Navel University of Engineering，Wuhan 43Oooo，China）

Abstract：To tackle the challnge of comprehensive analysis for the large-scale fast-locking mechanisms with tightly coupled multi-domain systems，a Modelica-based multi-domain modeling and simulation approach was proposed，focusing on the design and study of the mechanism’s structure，control and operating conditions. Firistly，the mechanism was partitioned into coherent submodules，for which a permanent magnet synchronous motor's electromagnetic model and the dynamics of the ball screw and push-rod assemblies were formulated.These component models were assembled into both subsystem and full-chain models within simulation platform. Secondly，the particle swarm optimization algorithm was used to optimize the control parameters of the drive system.Finall，three operating scenarios were evaluated— standard position control， fixed angular offset about the Z -axis，and dynamic three-axis angular offsets— to assess their influence on upright-positioning accuracy within a one-second setling time. Simulation results were validated against prototype experiments，demonstrating high positioning precision under all tested conditions. These findings confirm soundness of the mechanism’s design and the fidelity of the simulation models，and they ofer a methodological reference for the development of other large-scale，multidomain servo-controlled systems and their modeling-simulation approaches.

Keywords：large-scale fast-locking mechanism； multi-domain modeling； permanent magnet synchronousmotor；servo control； righting accuracy；particle swarm optimization

0引言

随着电机制造技术和电力电子技术迅猛发展，交流电机控制技术已经被广泛地运用于工程控制领域中并且不断进步，取得了令人瞩目的成就，持续在航空航天[1-2]、数控机床[3]、轨道交通[4]等重要领域中发挥重要作用。（剩余12181字）
