基于ANSYS的FSAC赛车制动盘热仿真优化

打开文本图片集

中图分类号： U469.6+96 文献标志码：A

Thermal simulation optimization of brake disc for FSAC racing cars using ANSYS

WU Yongjunjie，DONG Xiujuan，LAN Jianping，YANG Yahui （School of Automotive Engineering，Hubei University of Automotive Technology，Shiyan 442O02，China）

Abstract： To address the issue of brake disc overheating during emergency braking in Formula Student Autonomous China （FSAC）racing cars，which impairs braking performance and shortens disc lifespan，a structural optimization scheme featuring a slanted vent structure is proposed. ANSYS finite element analysis was conducted to compare the temperatures of brake discs with cooling vents angled at 60∘ ， 70∘ ， 80∘ ，and 90∘ relative to the disc plane. Simulations demonstrate that 70∘ -angled vents reduce peak braking temperatures by about 6 C compared to conventional 90∘ straight vents，effectively mitigating brake fade while enhancing efciency and longevity.Track testing validated the simulation results，confirming structural efficacy.This design provides a reference for brake disc design in other racing teams.

Key words： ANSYS finite element；thermo-mechanical coupling；structural optimization；brake disc for SAC racing cars

中国大学生无人驾驶方程式大赛（Formula Student Autonomous China，FSAC），由中国汽车工程学会与合肥市人民政府共同主办，旨在由各大高校学生构想、设计、制造、开发并完成一辆小型无人驾驶方程式赛车并参加比赛，能够让更多的大学生近距离参与到新能源汽车技术与智能汽车技术的发展中。（剩余7009字）
