基于反激变压器的锂电池组混合交错均衡方案

打开文本图片集

关键词：储能系统;锂电池组；反激变压器；混合均衡拓扑；自适应交错均衡控制DOI：10.15938/j. emc.2025.06.013中图分类号：TM911 文献标志码：A 文章编号：1007-449X（2025）06-0124-10

Hybird staggered equalization scheme of lithium battery pack based on flyback transformer

LI Bin 1，2 ， JIAO Linfeng 1，2 ，WANG Qingxuan³， ZHENG Zheng 1，2 ，WANG Hao 1，2 （1.School of Electrical Engineering and Automation，Henan Polytechnic University，Jiaozuo 454003，China; 2.Henan International Joint Laboratoryof Direct Driveand Control of Inteligent Equipment，Jiaozuo 454003，China; 3. School of Artificial Intelligence，Jiaozuo University，Jiaozuo 4540oO，China）

Abstract：Aiming at the problem of voltage inconsistency among individual cels in lithium battery packs of energy storage systems，a hybrid balancing topology based on flyback transformer and an adaptive interleaved equalization control strategy for the battery pack were proposed. Through the analysis of the equalization topology and control strategy，this scheme not only has two types of equalization modes，cel to pack and pack to cell，but also adjusts the balance type according to the state of the batery to ensure that the balance circuit is always in the best working state.Through the analysis of simulation results in terms of speed，effciency and cost，it is concluded that this scheme has a significant improvement compared with the control group，with the equalization speed increased by more than 40% ，the balance efficiency increased by about 3% ，and the cost reduced by 66% . The above indicates that this scheme has strong theoretical significance and practical value. Then，experimental analysis was conducted under three working conditions of static，charging and discharging，verifying accuracy and effectiveness of the proposed

scheme.

Keywords：energy storage system; lithium-ion battery packs; flyback transformer;hybrid equalization topology ；adaptive interleaved equalization control

0引言

储能技术作为解决可再生能源波动性的核心问题的关键技术，受到了广泛的研究和关注。（剩余13934字）
