一种高功率密度抗辐射POL电源设计

打开文本图片集

欧长江（1991—），男，工程师，主要从事厚膜混合集成抗辐射电源研究。

关键词：高功率密度；抗辐射POL电源；小型化；高可靠中图分类号：TM46 文献标志码：A 文章编号：2095-8188（2025）06-0044-07DO1： 10.16628/j . cnki.2095-8188.2025.06.007

Design of High Power Density Radiation-Hardened POL Power Supply

OU Changjiang1，²， YANG Zhengnan 1，2 （1.The 43rd Research Institute of CETC，Hefei ，China; 2.Anhui Province Key Laboratory of Microsystem，Hefei 23Oo88， China）

Abstract：In viewof the increasing integration of spacesystemsand the demandof larger integratedcircuits for highpower density and miniaturized radiation-hardened point of load（POL）power suply，a design scheme for the high power density dual-circuit radiation-hardened POL power supplyis proposed.The circuit design， components selection，structural and technological design are described separately.Through simulations aualysis， analog experiments，sample testing and evaluation tests，the ratioualityof the design is verified.The power density of radiation-hardenedPOL power supplysignificantly exceeds thatof traditional power supply.In the caseof the limited areaof the single machineand the integration in spacesystem，itcan providea miniaturizedand lightweight high-power radiation-hardened POL power supply platform.

Keywords：high-powerdensity； radiation-hardened POL powersupply； miniaturization;high reliability

0 引言

随着航天设计集成度的日益提高，更大规模集成电路，如FPGAVirtex7系列、160 Gflops浮点处理能力的多核DSP、10Gbps以上传输带宽的并串转换收发芯片、高速高带宽A/D等被广泛应用于航天领域，迫切需求高功率密度抗辐射负载点（POL）电源的[2]。（剩余5897字）
