紧凑型半导体激光器光纤耦合模块设计

打开文本图片集

中图分类号：TN248 文献标志码： A

Design of compact fiber coupling module of diode laser

YUTiancheng¹，LIANG Shuli²，TIAN Lei，LIANG Xiaoli³ （1.Nanjing Electronic Equipment Research Institute， Nanjing 21Oooo， Jiangsu， China; 2.Beijing Institute of Tracking and Communication Technology，Beijing 1Ooo94， China; 3.Suzhou Industrial Park Big Data Management Center， Suzhou 2l5OOO， Jiangsu， China）

Abstract：A Fiber coupling module based on multiple laser diodes is discussed.16 laser diodes are combined in space by the isosceles right-angle prisms and knife edge right-angle prisms，which make the beams combined on the slow axis and fast axis.Finally，beams can be coupled with the theoretical efficiency of 84% into a fiber with the diameter of 105μm and the numerical aperture of 0.22. In the principle test， the output power of module achieved 37.6W with the efficiency of 73.4% ：

Keywords：diodelaser；fibercoupling；spatial combination

0 引言

高功率半导体激光器具备有电光效率高、可靠性高、体积小、质量轻、易批量化生产等优势，广泛应用于材料加工、激光泵浦和国家安全等领域[1-2]。（剩余3498字）
