基于液晶空间光调制器的全息再现像设计
打开文本图片集
关键词：计算全息;傅里叶变换;Gerchberg-Saxton算法;采样间隔;液晶空间光调制器中图分类号：0438.1 文献标志码：A doi：10.37188/CO.2024-0224 CSTR：32171.14.CO.2024-0224
Abstract： Based on the principle of computer-generated holograms reproduction imaging，this paper used the Gerchberg-Saxton （GS） algorithm to iteratively solve the phase distribution of the original simulation images under different characteristic parameters （line width， ring diameter）and diffrent calculated sampling intervals by performing direct and inverse Fourier transforms on the optical field distributions of the input and output planes，and the corresponding reproduced images were obtained by simulation calculation. The optical path of the holographic reproduction experiment was constructed by using the liquid crystal spatial light modulator，and the reproduction experiment was carried out by loading the phase distribution maps of different original simulation images， the holographic reproduction images of far-field difraction were taken by the camera，and the actual feature size of the reproduced images was obtained by image processing. The experimental results show that the feature size of the reproduced images is basically linear with the characteristic size of the original simulation images.Furthermore， the reproduction image size shows a non-linear change relationship with the sampling intervals of the simulation calculation， which is consistent with the derived theoretical calculation relationship curve.In order to further verify the correctnessof the conclusion，when the size of the expected reproduced image is designed as the ring diameter of 0.943mm and the line width of the central cross of 0.015mm . The characteristic size and sampling interval of the original simulation image of the expected target are obtained by the simulation calculation as the line width of 3 pixel， the ring diameter of 594 pixel and the sampling interval of 25μm ， respectively. The ring diameter and line width of the holographic reproduction image， as measured by the reproduction experiment， are 0.93mm and 0.017mm 5 respectively. The error accuracy is within 0.02mm . The findings of this study provide an effective reference for application scenarios such as holographic display and AR/VR display to improve the authenticity of virtual display image size.
Key words： computer-generated holography; Fourier transform; Gerchberg-Saxton algorithm; sampling intervals; liquid crystal spatial light modulator
1引言
随着计算机技术的迅猛发展，全息技术经历了光学全息、数字全息和计算全息三个时代[1-3]，对计算精度的要求越来越高。（剩余15678字）
