连杆蝶阀运动轨迹分析

打开文本图片集

摘 要：连杆蝶阀在很多场合都得到了应用。通过对连杆蝶阀的运动轨迹进行分析，得到了连杆蝶阀各参数之间的关系式和阀板运动轨迹，从而更好的了解阀门的运动特性，对流道进行分析；然后调整各参数，通过求得的关系式进行试算，得到最理想的运动特性。优化设计，以满足各使用场合的要求。

关键词：连杆蝶阀；四连杆机构；运动轨迹；关系式

THE ANALYSIS OF THE MOTION TRAJECTORY OF THE LINKBUTTERFLY VALVE

Li Hua1，2 Gai Xiaoming1，2 Li Qin3 Tian Kui3

（1.Hebei Province Technology Innovation Center of Metallurgical Equipments  Qinhuangdao 066318， China；

2. Qinhuangdao Qinye Heavy Industry Co.， Ltd.  Qinhuangdao  066318，China；

3.Drilling Technology Research Institute of Bohai Drilling Engineering Co.， ltd.  CNPC  Renqiu 062550，China）

Abstract：Link butterfly valve has been applied in many occasions. Through the analysis of the motion trajectory of the link butterfly valve， the relationship between the parameters of the link butterfly valve and the motion trajectory of the valve plate are obtained， so as to better understand the motion characteristics of the valve， analyze the flow channel， and then adjust the parameters. Through the trial calculation of the obtained relationship， the most ideal motion characteristics are obtained， and the design is optimized to meet the requirements of various applications.

Key words：Link Butterfly Valve; Four Bar Linkage; Motion Trajectory; Relation

0 前 言

随着冶炼技术的不断发展，冶金阀门的性能也在不断提高。（剩余4532字）
