钻石排列OLED手机裸眼3D显示

打开文本图片集

关键词：柱状透镜光栅；裸眼3D显示；OLED像素复用；颜色偏差 中图分类号：TN27 文献标识码：A doi：10.37188/CJLCD.2025-0078 CSTR：32172.14.CJLCD.2025-0078

Abstract： In order to explore the glasses-free 3D display efect on the mobile terminal mobile phones， based on the glasses-free 3D display technology lenticular lens grating，a glasses-free 3D display solution is proposed that is suitable for the sub-pixel configuration mainstream OLED screen mobile phones with diamond pentile sub-pixel configuration. Lens grating design，pixel mapping analysis， display system design， crosstalk reduction， color balance correction are included in the solution.A method is introduced which can reduce color deviation by turning fhalf the red sub-pixels or half the blue sub-pixels when using a lenticular lens grating to cover the OLED display screen a mobile phone for glasses-free 3D display. Finally，a mobile phone was used to verify the efect the display method. The solution which illminate 50% the red or blue sub-pixels， retain 70% the green sub-pixels can effectively improve the glasses-free 3D display color deviation OLED mobile phones are showed in the evaluation results.

words： lenticular lens；glasses-free 3D display； sub-pixel multiplexing;color deviation

1引言

立体三维（3D）显示技术的研究在显示领域持续至今，对于裸眼3D显示技术而言，无设备辅助的3D效果观看需要进行大量的数据传输和运算，因此随着现代高清、超高清显示技术的推进以及5G技术和图像处理器的发展，裸眼3D显示技术再次成为最吸引人的研究方向之一[1-5]。（剩余8262字）
