一种新型双排桩挡土墙

打开文本图片集

【摘    要】：针对传统双排桩挡土墙顶部连梁不能满足道路横向较大高差需求的问题，以实际工程为例，设计了一种用于河岸护坡的新型双排桩挡土墙，将悬臂式挡墙和双排桩挡墙结合，能够满足墙顶高差变化的需求；通过线弹性基床系数法（m法）和有限元法的对比，验证了m法对该挡土墙有效性。

【关键词】：双排桩；挡土墙；m法；道路；边坡支护

【中图分类号】：TU476.4 【文献标志码】：C 【文章编号】：1008-3197（2023）02-27-03

【DOI编码】：10.3969/j.issn.1008-3197.2023.02.006

A Double-Row Pile Retaining Wall

ZHAO Peng1， WU Gang2

（1. Central & Southern China Municipal Engineering Design and Research Institute Co.Ltd.， Xi′an 71000，China；

2. Shenzhen Municipal Design & Research Institute Co. Ltd.， Shenzhen 518000，China）

【Abstract】：In view of the problem that the top coupling beam of traditional double-row pile retaining wall can not meet the demand of large horizontal height difference of road， based on actual projrct， the paper designes a new type of double-row pile retaining wall for river bank slope protection. This type of retaining wall combines the cantilever retaining wall with the double-row pile retaining wall， which can realize the demand of the change of the top height difference. The effectiveness of M method for this type of retaining wall are tested by comparing M method and finite element method.

【Key words】：double row pile; retaining wall; M method; slope support

双排桩挡土墙是边坡支护常见的挡墙形式，通过顶部连系梁形成门式结构，大大提高了挡土结构的刚度[1]。（剩余2822字）
