新能源汽车高压线束常用屏蔽结构浅析

打开文本图片集

【摘  要】本文主要概括目前高压线束常用的3种屏蔽方式，通过分析比较几种屏蔽结构及优缺点，发现未来高压导线的发展主要有两个趋势，分别是：①优化目前导线的编织屏蔽结构，使其成本降低且变得易于加工；②高压导线去屏蔽。

【关键词】高压线束；电磁屏蔽；导线去屏蔽；屏蔽套管；滤波器

中图分类号：U463.6    文献标志码：A    文章编号：1003-8639（ 2023 ）01-0011-02

Analysis on Common Shielding Structure of High Voltage Wiring Harness for New Energy Vehicles

WANG Ya-fang，FENG Wei，MA Hong-fei

（Hebi Tianhai Global Electric Co.，Ltd.，Hebi 458030，China）

【Abstract】This paper mainly summarizes three commonly used shielding methods for high-voltage wire harness at present. By analyzing and comparing several shielding structures and their advantages and disadvantages，it is found that there are two main trends in the development of high-voltage wire in the future，namely： ① optimize the current braided shielding structure of wire to reduce its cost and make it easier to process；② High voltage wire is unshielded.

【Key words】high voltage harness；electromagnetic shielding；wire unshielding；shielding sleeve；wave filter

当前新能源汽车正朝着高电压大电流方向发展，有的高压系统承受的电压高达800V，电流高达660A，如此大的电流和电压会产生电磁辐射，电磁辐射会干扰其它电子元器件的正常运行，所以高压线束在设计时必须要考虑电磁干扰问题。（剩余2837字）
